Classic

The Extreme Heavy-Duty Rack-Mount Case

Image related to Pelican products and manufacturing

Maximum Shock & Vibration Protection

The Classic Rack case is a smooth finished roto case with a 19-inch wide EIA (IEC 60297) standard rack and a variety of rack depths including 17", 18", 20", 23", 25", 28", and 33".

Extremely rugged, rotomoulded Peli Classic Rack cases have demonstrated their strength in the field thousands of times over, protecting fragile equipment from damage in storage and during transport. Our precision-tuned elastomeric shock-mount systems provide maximum shock and vibration protection for sensitive electronics and equipment. Get started with the strongest, most secure rack in the industry.

Specs

Sizes
3U, 4U, 5U, 6U, 7U, 9U, 10U, 11U, 14U, 21U, and 26U
Fragility Level
15 – 30 G’s
Payload
8-shock mounts: 9.1 kg to 77 kg. 16-shock mounts: 72.6 kg to 154 kg.
Sway Space
50.8mm for maximum ability to decelerate shock forces and provide airflow
Base Features
Colour: Grey (133) Zinc Cobalt-Black Non-Locking Catch-and-Strike Hardware (HCB) Black Stainless-Steel Handles Heavy-Duty Reinforced Aluminium Rack Frame

Shock & Vibration System

Cylindrical Shock Mounts isolate equipment from vibration as well as impact forces. Shock mounts vary in size depending on protection requirements - from delicate equipment to rugged electronics.

Applications

  • Military Rapid Deployment
  • Rack-Mountable Precision Test Equipment
  • Electro-Mechanical
  • Medical Diagnostic Equipment
  • Memory Storage Devices
  • Meteorological Instruments
  • Mobile Operations
  • Broadcast and Video Gear
  • Laboratory Equipment
  • Aerospace Instrumentation

Customisation

Classic Rack cases are fully configurable and made to order. They can also be customised by our Technical Sales solution team. Contact us for a completely customised solution or if you need a 1U extension to any standard U size.

Peli-Hardigg & Rack-Mount Cases

Configuration Options

Configure your case for your exact needs. Configuration options include casters, document holders, humidity indicator, bash plates to prevent forklift puncture and more.

Available Case Colours

Black Carbon Steel (HNB)

Stainless Steel Black (SSB)

Comfort Grip Plastic

Stainless Steel

Closed Gasket with PRV

Humidity Indicator

Caster Storage in Lid

Bottom Casters

Lockable Catch

Card Holder

ID Plate

Front Label

ATA/STD Labels

Custom Stenciling

Lifting Rings/Tie Down Rings

Sliding Drawers

Classic Rack Sizing Options

U Size Catalogue Rack Depth Lid Depth Back Lid Depth Weight
3U DE2410-02-24-02 20.00"

(50.8 cm)

 2.50"

(6.35 cm)

 2.50"

(6.35 cm)

 43 lbs (19.5 kg)
3U DE2410-02-24-05 20.00"

(50.8 cm)

 2.50"

(6.35 cm)

 5.25"

(13.34 cm)

 44 lbs (20 kg)
3U DE2410-05-24-05 20.00"

(50.8 cm)

 5.25"

(13.34 cm)

 5.25"

(13.34 cm)

 45 lbs (20.4 kg)
3U DE2410-02-35-02 33.00"

(83.82 cm)

 2.50"

(6.35 cm)

 2.50"

(6.35 cm)

 50 lbs (22.7 kg)
3U DE2410-02-35-05 33.00"

(83.82 cm)

 2.50"

(6.35 cm)

 5.25"

(13.34 cm)

 51 lbs (23.1 kg)
3U DE2410-05-35-05 33.00"

(83.82 cm)

 5.25"

(13.34 cm)

 5.25"

(13.34 cm)

 52 lbs (23.6 kg)
3U TR2410-023502RCK02 27.00"

(68.58 cm)

 N/A

N/A

57 lbs (26 kg)
U Size Catalogue Rack Depth Lid Depth Back Lid Depth Weight
4U DE2412-02-24-02 20.00"

(50.8 cm)

 2.50"

(6.35 cm)

 2.50"

(6.35 cm)

 50 lbs (22.7 kg)
4U DE2412-02-24-05 20.00"

(50.8 cm)

 2.50"

(6.35 cm)

 5.25"

(13.34 cm)

 51 lbs (23.1 kg)
4U DE2412-05-24-05 20.00"

(50.8 cm)

 5.25"

(13.34 cm)

 5.25"

(13.34 cm)

 52 lbs (23.6 kg)
4U DE2412-02-35-02 33.00"

(83.82 cm)

 2.50"

(6.35 cm)

 2.50"

(6.35 cm)

 53 lbs (24 kg)
4U DE2412-02-35-05 33.00"

(83.82 cm)

 2.50"

(6.35 cm)

 5.25"

(13.34 cm)

 54 lbs (24.5 kg)
4U DE2412-05-35-05 33.00"

(83.82 cm)

 5.25"

(13.34 cm)

 5.25"

(13.34 cm)

 55 lbs (25 kg)
U Size Catalogue Rack Depth Lid Depth Back Lid Depth Weight
5U DE2414-02-24-02 20.00"

(50.8 cm)

 2.50"

(6.35 cm)

 2.50"

(6.35 cm)

 52 lbs (23.6 kg)
5U DE2414-02-24-05 20.00"

(50.8 cm)

 2.50"

(6.35 cm)

 5.25"

(13.34 cm)

 54 lbs (24.5 kg)
5U DE2414-05-24-05 20.00"

(50.8 cm)

 5.25"

(13.34 cm)

 5.25"

(13.34 cm)

 56 lbs (25.4 kg)
5U DE2414-02-27-02 25.00"

(63.5 cm)

 2.50"

(6.35 cm)

 2.50"

(6.35 cm)

 53 lbs (24 kg)
5U DE2414-02-27-05 25.00"

(63.5 cm)

 2.50"

(6.35 cm)

 5.25"

(13.34 cm)

 55 lbs (25 kg)
5U DE2414-05-27-05 25.00"

(63.5 cm)

 5.25"

(13.34 cm)

 5.25"

(13.34 cm)

 57 lbs (25.9 kg)
5U DE2414-02-35-02 33.00"

(83.82 cm)

 2.50"

(6.35 cm)

 2.50"

(6.35 cm)

 54 lbs (24.5 kg)
5U DE2414-02-35-05 33.00"

(83.82 cm)

 2.50"

(6.35 cm)

 5.25"

(13.34 cm)

 56 lbs (25.4 kg)
5U DE2414-05-35-05 33.00"

(83.82 cm)

 5.25"

(13.34 cm)

 5.25"

(13.34 cm)

 58 lbs (26.3 kg)
U Size Catalogue Rack Depth Lid Depth Back Lid Depth Weight
6U DE2416-02-24-02 20.00"

(50.8 cm)

 2.50"

(6.35 cm)

 2.50"

(6.35 cm)

 56 lbs (25.4 kg)
6U DE2416-02-24-05 20.00"

(50.8 cm)

 2.50"

(6.35 cm)

 5.25"

(13.34 cm)

 57 lbs (25.9 kg)
6U DE2416-05-24-05 20.00"

(50.8 cm)

 5.25"

(13.34 cm)

 5.25"

(13.34 cm)

 59 lbs (26.8 kg)
6U DE2416-02-27-02 25.00"

(63.5 cm)

 2.50"

(6.35 cm)

 2.50"

(6.35 cm)

 57 lbs (25.9 kg)
6U DE2416-02-27-05 25.00"

(63.5 cm)

 2.50"

(6.35 cm)

 5.25"

(13.34 cm)

 59 lbs (26.8 kg)
6U DE2416-05-27-05 25.00"

(63.5 cm)

 5.25"

(13.34 cm)

 5.25"

(13.34 cm)

 60 lbs (27.2 kg)
U Size Catalogue Rack Depth Lid Depth Back Lid Depth Weight
7U DE2418-02-20-02 18.00"

(45.72 cm)

 2.50"

(6.35 cm)

 2.50"

(6.35 cm)

 59 lbs (26.8 kg)
7U DE2418-02-20-05 18.00"

(45.72 cm)

 2.50"

(6.35 cm)

 5.25"

(13.34 cm)

 61 lbs (27.7 kg)
7U DE2418-05-20-05 18.00"

(45.72 cm)

 5.25"

(13.34 cm)

 5.25"

(13.34 cm)

 63 lbs (28.6 kg)
7U DE2418-02-27-02 25.00"

(63.5 cm)

 2.50"

(6.35 cm)

 2.50"

(6.35 cm)

 60 lbs (27.2 kg)
7U DE2418-02-27-05 25.00"

(63.5 cm)

 2.50"

(6.35 cm)

 5.25"

(13.34 cm)

 62 lbs (28.1 kg)
7U DE2418-05-27-05 25.00"

(63.5 cm)

 5.25"

(13.34 cm)

 5.25"

(13.34 cm)

 64 lbs (29 kg)
7U DE2418-02-35-02 33.00"

(83.82 cm)

 2.50"

(6.35 cm)

 2.50"

(6.35 cm)

 63 lbs (28.6 kg)
7U DE2418-02-35-05 33.00"

(83.82 cm)

 2.50"

(6.35 cm)

 5.25"

(13.34 cm)

 65 lbs (29.5 kg)
7U DE2418-05-35-05 33.00"

(83.82 cm)

 5.25"

(13.34 cm)

 5.25"

(13.34 cm)

 67 lbs (30.4 kg)
U Size Catalogue Rack Depth Lid Depth Back Lid Depth Weight
9U DE2421-02-27-02 25.00"

(63.5 cm)

 2.50"

(6.35 cm)

 2.50"

(6.35 cm)

 70 lbs (31.8 kg)
9U DE2421-02-27-05 25.00"

(63.5 cm)

 2.50"

(6.35 cm)

 5.25"

(13.34 cm)

 71 lbs (32.2 kg)
9U DE2421-05-27-05 25.00"

(63.5 cm)

 5.25"

(13.34 cm)

 5.25"

(13.34 cm)

 73 lbs (33.1 kg)
9U DE2421-02-35-02 33.00"

(83.82 cm)

 2.50"

(6.35 cm)

 2.50"

(6.35 cm)

 71 lbs (32.2 kg)
9U DE2421-02-35-05 33.00"

(83.82 cm)

 2.50"

(6.35 cm)

 5.25"

(13.34 cm)

 72 lbs (32.7 kg)
9U DE2421-05-35-05 33.00"

(83.82 cm)

 5.25"

(13.34 cm)

 5.25"

(13.34 cm)

 74 lbs (33.6 kg)
U Size Catalogue Rack Depth Lid Depth Back Lid Depth Weight
10U DE2121-02-18-02 17.00"

(43.18 cm)

 2.50"

(6.35 cm)

 2.50"

(6.35 cm)

 47 lbs (21.3 kg)
10U DE2121-02-18-05 17.00"

(43.18 cm)

 2.50"

(6.35 cm)

 5.25"

(13.34 cm)

 49 lbs (22.2 kg)
10U DE2121-05-18-05 17.00"

(43.18 cm)

 5.25"

(13.34 cm)

 5.25"

(13.34 cm)

 51 lbs (23.1 kg)
10U DE2121-02-30-02 28.00"

(71.12 cm)

 2.50"

(6.35 cm)

 2.50"

(6.35 cm)

 76 lbs (34.5 kg)
10U DE2121-02-30-05 28.00"

(71.12 cm)

 2.50"

(6.35 cm)

 5.25"

(13.34 cm)

 78 lbs (35.4 kg)
10U DE2121-05-30-05 28.00"

(71.12 cm)

 5.25"

(13.34 cm)

 5.25"

(13.34 cm)

 80 lbs (36.3 kg)
U Size Catalogue Rack Depth Lid Depth Back Lid Depth Weight
11U DE2425-02-27-02 25.00"

(63.5 cm)

 2.50"

(6.35 cm)

 2.50"

(6.35 cm)

 75 lbs (34 kg)
11U DE2425-02-27-05 25.00"

(63.5 cm)

 2.50"

(6.35 cm)

 5.25"

(13.34 cm)

 78 lbs (35.4 kg)
11U DE2425-05-27-05 25.00"

(63.5 cm)

 5.25"

(13.34 cm)

 5.25"

(13.34 cm)

 81 lbs (36.7 kg)
11U TR2425-052705RCK03 25.00"

(63.5 cm)

 N/A

N/A

100 lbs (45.5 kg)
U Size Catalogue Rack Depth Lid Depth Back Lid Depth Weight
14U DE2430-02-27-02 25.00"

(63.5 cm)

 2.50"

(6.35 cm)

 2.50"

(6.35 cm)

 79 lbs (35.8 kg)
14U DE2430-02-27-05 25.00"

(63.5 cm)

 2.50"

(6.35 cm)

 5.25"

(13.34 cm)

 81 lbs (36.7 kg)
14U DE2430-05-27-05 25.00"

(63.5 cm)

 5.25"

(13.34 cm)

 5.25"

(13.34 cm)

 83 lbs (37.7 kg)
U Size Catalogue Rack Depth Lid Depth Back Lid Depth Weight
21U DE2442-02-27-02 25.00"

(63.5 cm)

 2.50"

(6.35 cm)

 2.50"

(6.35 cm)

 103 lbs (46.7 kg)
21U DE2442-02-27-05 25.00"

(63.5 cm)

 2.50"

(6.35 cm)

 5.25"

(13.34 cm)

 105 lbs (47.6 kg)
21U DE2442-05-27-05 25.00"

(63.5 cm)

 5.25"

(13.34 cm)

 5.25"

(13.34 cm)

 107 lbs (48.5 kg)
U Size Catalogue Rack Depth Lid Depth Back Lid Depth Weight
26U DE2652-02-25-02 23.00"

(58.42 cm)

 2.50"

(6.35 cm)

 2.50"

(6.35 cm)

 119 lbs (54 kg)
26U DE2652-02-25-05 23.00"

(58.42 cm)

 2.50"

(6.35 cm)

 5.25"

(13.34 cm)

 121 lbs (54.9 kg)
26U DE2652-05-25-05 23.00"

(58.42 cm)

 5.25"

(13.34 cm)

 5.25"

(13.34 cm)

 123 lbs (55.8 kg)
